Mercedes Star Diagnosis Tool MB SD Connect C4 Compact 4 with Panasonic CF29 laptop

Skype: jiutech9705

Email: Shirley at jiutech dot com

Tel: +86 13631686452

http://www.jiutechnet.com/sdp/863560/4/pd-4455529/10524074-2130968/MB_SD_Connect_C4_Compact_4_with_Panasonic_CF30_lap.html

Mercedes Star Diagnosis Tool MB SD Connect C4 Compact 4 MB star C4 with CF30 laptop

MB SD Connect C4 Compact 4 with Panasonic CF30 laptop

2016 STAR Diagnosis Tool MB SD Connect Compact 4 mb star c4 with CF30 laptop installed full software

mb star c4 sd connect mercedes c4 star sd connect mercedes das xentry installationed

 Support WIFI ( wifi card is inside)

Support Wifi,online technical service, Xentry in Develop model...


Software Content:

1)
 Multi-Languages
English, Chinese,
Czech,Danish,German,Greek,Spainsh,Finnish,French,Hungarian,Italian,Japanese,Korean,Dutch,
Polish,Portuguese,Romanian,Russian,Serbo,Slovak,Slovenian,Swedish, Turkish
2) Latest version
 09/2017 for DAS XENTRY 05/2016 for WIS /03/2016 for EPC / 2017/ SD Media
3) Xentry for new released 204/207/212/221 and Smart Model for 454 452 451 450, Support Benz cars, trucks, Sprinters, smart, etc
4) New car of B 246, CLS 218, SLK172, etc, released in this version
5) The car
 PL70 is added to Benz price list
6)
 Developer model Function: Mercedes-Benz engineer mode, remove limitations and open more functions.
7) Xentry Stop Software for quick close xentry
8) HHTwin stop software for quick close HHT
9) Support the software to be quickly Recovery
10) Support Online technical service

Passenger car support list:
A(176),  A(169),  A(168),  B(246),  B(245),  CLC(117),  C(204)  C(203),  C(202),  190(201),  E(212),  E(211),  E(210),  124(124),  S(222),  S(221),  S(220),  S(140),  S(126),  E(207),  CLK(209),  CLK(208),  CLS(218),  CLS(219),  CL(216),  CL(215),  CL(140)  SLK(172),  SLK(171),  SLK(170),  SL(231),  SL(230),  SL(129),  SL(107),  SLS(197),  M(166),  M(164),  M(163),  G(463),  G(461),  E(212),  E(211),  E(210),  124(124),  S(222),  S(221),  S(220),  S(140),  CLK(209),  CLK(208),  CLS(218),  CLS(219),  CL(216),  CL(215),  CL(140),  SLK(172),  SL(231),  SL(230),  SL(129),  SL(107),  SLS(197),  M(166),  M(164),  M(163),  G(460),  GL(164),  GLK(204),  R(251)


Van support list:
MB 100(631),  T1,  SprinterIII,  SprinterII,  SprinterI,  Sprinter900,  Citan,  Vito(639),  Vito(638), V(638),   Viano(639),  T2,  Vario,  Vaneo(414)

Truck  support  list:
Actros963/4,  Actros2,3,  AtegoIII,  AtegoII,  AxorII,  Eonic,  Zetros,  Actros,  Atego Light,  Atego Heavey,  HPN M96,  Atron,  HPN M2000,  SKL,  FSK,  Further model series

Unimogs support list:
U20,  UGN,  UHN

Busses  support list:
TRAVEGO,  INTOURO,  INTEGRO,  CITARO,  CAPACITY,  CITO,  TOURISMO,  O350/O403, CONECTO,  O404,  O405-O408,  Minibus,  OC500,  TOURO,  TOURINO,  MBC,  MULITEGO,  O500,  O500/OH,  OH,  OH368,  OF,  OF384,  LO,  O400,  FURTHER MODEL SERIES

Super sports cars support list:
SLR(199)

Industrial major assemblies support list:
OM904/924,  OM906/926,  OM457/460,  OM501/502,  GROVE5095,  GROVE5110,  GROVE5130-3,  GROVE5130-1,  GROVE4100,  GROVE5100,  TerexAC60, TerexAC100,  LTM 1030-2.1,  LTM 1040-2.1,  LTC 1045-3.1,  MTU 4R1000, MTU6R1000,  MTU6R1100,  MTU6R1300,  MTU6R1500

Features:

1. The new generation for Benz diagnostic equipment for all current and new coming Benz vehicles
2. It work with XP system.
3. It is including diagnosing, programming, simulation studying, repair information, automotive maintenance, technical service bulletin and so on.
4. The new Xentry is better than C3 DAS and it can connect Mercedes-Benz Internet to update and to programe and to set codes.
5. The SD-Connect is better and faster than Star.

Package Including:
1pc SD Connect
1pc 16pin cable
1pc 38pin cable
1pc 14pin cable
1pc 8pin cable
1pc net cable
1pc hard disk
1pc carrying case
1pc Panasonic CF30 laptop installed software.

Hardware configuration:
1. Intel Core Solo processor
2. Integrated WLAN function for wireless operation with SDconnect and connectionto the IT network
3. Ethernet interface for wired connection to the IT network
4. Possible connection of HMS 990 USB Measuring Technology
5. Power management controls power supply and consumption and adjusts to
specified power-saving mode
6. Transport case is included and provides protection for all components during transport and storage

Software
1) DAS: the automatically Diagnosis Assistance System
2) Xentry: New software released by Benz Company after 04/2009 by diagnosis new cars.
3)EPC.net: Electronic Parts Catalog
4) WIS.net: Workshop Information System
5) ST Finder: Part location finder
6) STARUTILITIES : the movement management system and self-test
7) SD Media : Video and PDF lessons
8) Developer model: Mercedes-Benz engineer mode, remove limitations and
open more functions.
9) PL 66: Price List to find out how much price by input the parts
number
10) Smart TAN Code: Opened special function in DAS program with Smart cars
450/451/452/454











Volvo vcads 88890180 interface with PTT 88890020 volvo vcads pro 2.4 in development

Skype: jiutech9705

MSN: jiutech9705 at hotmail dot com

Tel: +86 13631686452



volvo vcads interface 88890020 dev2tool exe

volvo vcads ptt 1.12 vcads 2.4



Set includes:

Volvo Interface 88890020;
USB cable;
88890027 8 Pin Cable;
VCADS 2.40 /PTT 1.12 Software DVD (in development model)

Support Brand :
All Volvo Bus, truck, construction



Languages:  english, cesky, dansk, Deutch, Espalol, Francis, Italiano, Magyar, Nederlands, Polski, Portuges, Romana, Srpski, Svenska, Turkce, Russian, Lietuva



Volvo vcads 2.40 Volvo 88890180 interface with PTT 88890020

The 88890180 communication unit enables PC to vehicle communication. The device connects to the PC via a USB cable or by wireless LAN using the 802.11 b/g standard.
Operating temperature range: -40 to +85°C (-40 to +185°F).
Storage temperature range: -40 to +125°C (-40 to 257°F).
Before the 88890020 communication unit can be used, a driver must be installed on the PC. In addition, a utility application (Admin0020) can be used to check the status of the device and update the firmware if and when needed.
There are three different ways, described below, of connecting communication unit88890180.
Via USB-cable
Connect the communication unit to the vehicle.
Connect the USB-cable between the communication unit and the PC.
Select communication unit 88890020 and USB-cable setting in window Alternative.
Directly to the communication unit

Connect the communication unit to the vehicle.
Select communication unit 88890020 and Direct to communication unit in window Alternative.
Security level Directly to the communication unit
Communication is performed using 128 bit WEP, Wired Equivalent Privacy. The WEP-key is generated automatically and is not seen during the configuration.
Via an access point
Note: Contact the local IT-support or network technician before installation.

Connect the communication unit to the vehicle.
Select communication unit 88890020 and Via an access point in window Alternative.
Security level Via an access point
There are three alternatives for this:
WEP and MAC-address. Communication is performed using 128 bit WEP, Wired Equivalent Privacy. The WEP-key is written in during configuration. The MAC-address is to be written into the access point for additional security.
WPA and PSK. Communication is performed via WPA, Wi-Fi Protected Access.
802.1x. Communication is performed using standard EAP_MSCHAP v2. The communication unit is then treated as a PC and will be logged on to the network using a username and password.

Product description for communication unit 88890020
Communication unit 88890020 has a number of different coloured LEDs. These LEDs show the status of the communication unit and indicate warnings, etc.

88890180 Communication Unit with protective cover

The Communication Unit 88890180 (previous parts number 88890180) is used to enable communication between a computer and a vehicle/machine.

The Communication Unit 88890180 includes a protective cover that encloses the wire connections and reduce situations where the unit loose connection with the vehicle

For detailed information regarding the Communication Unit , connection types , installation , LED’s description , fault tracing and software update , see the Tech Tool help.

Warranty
The Communication Unit has a 12 months warranty from delivery date. Please note the date when you received this product . This information is requires if the device needs to be replaced during the warranty .

How to send feedback
Please use your normal channels to report feedback and problems concerning the communication unit .

Connection types
There are three different ways of connecting the communication unit ; via USB cable . directly to the communication unit (wireless)or via access point (wireless) .The default connection type for the communication unit is via USB cable .

Update software (so called Firmware)
The Communication Unit includes software (so called firmware) that is updated on a regular basis . The updates are installed with Tech Tool DVD or in the network releases , and then needs to be downloaded to the Communication Unit through the Update software function . The Communication Unit must be connected both to a computer and a vehicle during the update .

RP1210 application support
The Communication Unit support the RP1210 . Other applications can use this device and perform vehicle/machine communication . The WLAN settings needs to be configured in the Tech Tool settings before you start your RP1210 application . The configurations , IP-addresses etc. are stored in an INI-file which can be used by other RP1210 applications . There is an off-line configuration application available on request ( only available in English).

Known problems
The installation procedure of the USb-driver for the communication unit will be performed the first time the unit is connected to a USB-port . This procedure will be repeated if the unit is connected to another USB-port on the same computer.


Checklist before returning a faulty product:

Check that all the LED sensors light up shortly when powering up the unit.
When connected only to USB: The unit should flash the LED sensors and then light the “power USB/Communication”-LED.
If the “power USB/Communication”-LED does not light up:
1. Try another USB-port
2. Check if windows performs “Installing device driver software”
3. Check the USB cable and try a different cable , or try another PC
4. If still no function, return the communication unit

When connected only to vehicle : The unit should flash the LED sensors and then light the “Power Vehicle”-LED .
If nothing light up:
1. Try replacing the vehicle cable.
2. Check that ignition is on , or try another vehicle.
If the “Critical Error” –LED is lit :
1. try to update the software .
2. If still no function , return the unit .
WLAN dose not work.
Consult your local IT support for advanced checking of WLAN.


Protective Cover 88880070

The protective cover for Communication Unit 88890020 is to reduce the possibility of losing connection with the vehicle or the PC via the USB cable.

The protective cover also protects the communication unit when it comes to acceleration damage (for example dropping ) as well as damage to the connectors .


CAUTION !
Only use the USB cable ( Parts no.88880024 ) with the correct connector dimensions , see picture .

1 Prepare the 88890020 , remove the lock mechanism , rubber pads and USB connector (plug A and plug B).
2 Place the 88890020 into the rubber protection .
3 Assemble the bracket.
Connect the vehicle and USB cable . Plug in plug A
Assemble the USB cable lock.
Assemble the vehicle cable lock .
4  The tool is now ready to use in the daily work .

Notice: we have V2.04.75 PTT software now, if you need it, please send me inquiry



 full Set Man T200  Man-cats Truck Diagnostic Scanner with CF30 laptop

MAN Diagnostic Scanner
T200 Dealer Level diagnosis system is ideally suited to use in a workshop as well as mobile usage.
MAN is an diagnosis system for electrical systems in MAN commercial vehicles.

Package List:
Hardware list:
1) T200 communication interface
2) T200 OBD2 cable
3) T200 12 pin round cable
4) T200 usb cable
5) D6420 laptop with full software installation.
Software List:
1)MAN 14.01  (Development level)
2) MANTIS  (spare parts)

3) MANWIS (workshop and repair manuals)


Support diagnosable systems:
Electronic brake systems (EBS).
Electronically controlled air suspension (ECAS).
Engine regulation (EDC).
Retarder.
Gearbox.
Air-conditioning systems.
Central computer.
Instrumentation.
Door module.
Airbag.

Possibilities of use:
Simple testing of actuators.
Visualisation and assessment of current sensor signals.
Identification of control unit in assembled condition.
Depiction of all stored diagnosis entries.
Fast orientation on vehicle by means of integrated overview wiring diagrams.

HD-OBD scantool (Heavy Duty On Board Diagnosis), read-out and presentation of data relevant to exhaust gas.






Payment Terms︰  T/T. Western Union. Money Gram. PayPal


Product Image


Full Set MB SD C4 Compact 4 With Dell E6420 Mercedes Star Diagnosis
